Key Features

• Compatibility: Hydra Part cylinder series 207 ; 307 ; 407 ; 507
• Bore sizes: 50 ; 63 ; 70 ; 80 ; 90 ; 100/115 mm options combined in range
• Intended use: complete reseal of specified series cylinders during overhaul or preventive maintenance
• Typical kit contents: piston seal ; rod seal ; wiper ; static o rings as used in cylinder rebuilds
• Use case: suited to construction ; agricultural and industrial rams within the listed series
• Fitment check: confirm cylinder plate or purchase record for exact series before fitment

Key Features

• Valve: 90L monoblock ; motor spool ED-2
• Inlet: Right hand inlet
• Function: Motor spool profile for bidirectional motors
• Use: Maintained flow to motors ; reduced cavitation risk
• Additional info: See product data sheet for detailed measurements

Key Features

• Compatibility: Baltrotors rotators GR30 ; GR30A ; GR30PF family
• Rotator type: Grapple rotator with eye upper connection and axle lower mount ; unlimited rotation
• Intended use: service kit for original seals used in GR30 series rotator heads
• Typical kit contents: rotary housing ; shaft and port sealing elements needed for leak repair
• Applications: forestry and small agricultural cranes using GR30 family rotators
• Fitment note: verify exact GR30 variant before installation to match geometry

Key Features

• Compatibility: Hydra Part MV high torque orbital motors ; Zi pattern
• Intended use: renew housing ; shaft and cover seals to prevent oil leakage and pressure loss
• Typical kit contents: shaft seal ; case drain and port seals ; body o rings used on MV motors
• Applications: drive motors on conveyors ; winches ; swing drives and attachments
• Service note: inspect shaft surface finish ; replace or sleeve if worn to protect new seal
• Fitment check: confirm MV motor code on nameplate to match kit version

Key Features

• Capacity: 15 l
• Neck flange: 123 mm ac
• Material: steel
• Orientation: vertical ; horizontal mounting
• Use: mini hydraulic power packs reservoir
• Compatibility: ac motor power pack builds ; 123 mm neck accessories

Key Features

• Capacity: 15 l
• Neck flange: 120 mm dc
• Material: steel
• Orientation: vertical ; horizontal mounting
• Use: mini hydraulic power packs reservoir
• Compatibility: dc motor power pack builds ; 120 mm neck accessories

Key Features

• Compatibility: Hydra Part cylinder series 206 ; 306 ; 406 ; 506
• Bore sizes: 50 ; 63 ; 70 ; 80/90 ; 100 mm range
• Intended use: resealing of medium bore cylinders in the specified series to recover performance
• Typical kit contents: piston ; rod ; wiper and related static seals typical to cylinder service kits
• Applications: suitable for rams on trailers ; loaders ; compact equipment within these series
• Fitment check: use the series code stamped on the cylinder to select the correct kit

Key Features

• Function: vent ; filter air for hydraulic reservoir
• Interface: flange mount options ; e.g. 83 mm 6 hole pattern
• Element: replaceable breather element
• Use: prevents contamination ; equalises tank pressure
• Application: hydraulic component

Key Features

• Interface: 123 mm tank flange to central manifold
• System: ac motor power pack
• Function: routes pump ; return ; relief to cetop stack
• Compatibility: cetop 3 spacer 30 mm ; stackable manifold 3/8 side ports
• Use: base for ac mini power pack assemblies

Key Features

• Spool type: motor spool type 2
• Application: bi directional hydraulic motors
• Behavior: neutral geometry suited to motor load decel
• Compatibility: 240l valve family
• Positions: 3 position ; spring return to neutral

Key Features

• Valve: 90L monoblock ; double acting cylinder spool ED-1
• Inlet: Right hand inlet
• Function: Cylinder spool with power both directions
• Use: Double acting actuators
• Additional info: See product data sheet for detailed measurements

Key Features

• Application: Hydraulic brake actuation for agricultural ; mobile equipment
• Rod options: Ø25 mm ; Ø30 mm variants
• Working pressure: 200 bar nominal ; 250 bar max
• Speed: 0.5 m/s
• Temperature range: -25 °C to +80 °C
• Notes: Fork rod end versions suit bogie braking linkages

Key Features

• Compatibility: Hydra Part MSY series disc valve orbital motors ; Zi pattern
• Motor notes: MSY motors use disc valve distribution offering higher torque capability in family
• Intended use: seal replacement for output shaft ; cover and porting to resolve leaks
• Typical kit contents: shaft seal ; housing o rings ; drain port seals commonly replaced on service
• Applications: industrial and mobile drives requiring rugged low speed high torque performance
• Selection note: check MSY displacement code and mounting to select correct kit

Key Features

• Function: Hydraulic proportional pilot conversion kit
• Kit code: 81M
• Compatibility: 90L ; 100L ; 120L ; 150L valves
• Use: Remote proportional control of spools
• Additional info: See product data sheet for detailed measurements

Key Features

• Spool type: single acting type 3 . a port active ; b port plugged
• Positions: 3 position ; spring return to neutral
• Use: single acting cylinders
• Compatibility: 150l valve family
• Note: requires appropriate spring kit for single acting

Key Features

• Series: 80L GS sectional control valve
• Applications: mobile hydraulics ; loaders ; cranes
• Compatibility: Hydra Part GS family ; alternative to Walvoil SD series in same size
• Fluid: mineral oil ; 15–75 cSt operating range
• Max pressure class: up to 315 bar per series

Key Features

• Capacity: 12 l
• Neck flange: 123 mm ac
• Material: steel
• Orientation: vertical ; horizontal mounting
• Use: mini hydraulic power packs reservoir
• Compatibility: ac motor power pack builds ; 123 mm neck accessories

Key Features

• Capacity: 12 l
• Neck flange: 120 mm dc
• Material: steel
• Orientation: vertical ; horizontal mounting
• Use: mini hydraulic power packs reservoir
• Compatibility: dc motor power pack builds ; 120 mm neck accessories

Key Features

• Application: tractor top link cylinder load holding
• Type: double pilot operated check
• Port size: 3/8' bsp
• Rated flow: 25 to 50 l/min options
• Use: prevents drift ; allows controlled retraction on pilot

Key Features

• Compatibility: Hydra Part standard double acting cylinders ; bores 45 ; 80/90 mm
• Intended use: rebuild and reseal standard cylinders to restore pressure integrity and stop external leakage
• Typical kit contents: piston ; rod ; buffer and wiper seals plus associated o rings for cylinder service
• Applications: general mobile hydraulics ; loaders ; attachments ; ag and industrial equipment
• Maintenance note: verify bore ; rod ; and series before ordering to match correct seal sizes
• Fluid compatibility: formulated for use with mineral hydraulic oils common to mobile machinery

Key Features

• Type: rotary lever conversion kit
• Compatibility: 45l ; 50l control valves
• Operation: lever rotates to actuate spool via cam
• Benefit: compact side clearance vs straight lever
• Use: consoles with limited front to back space

Key Features

• Standard: cetop 3 ; iso 4401-03 ; din 24340
• Ports: p ; t 1/2" bspp ; a ; b 3/8" bspp
• Relief cavity: main pressure relief cavity provided ; blanking plug when no cartridge
• Max working pressure: 315 bar
• Circuit: parallel
• Stations: 1 ; 2 ; 3 ; 4 ; 5 ; 6 options
• Material: steel
• Use: mounting of ng6 directional valves on mini power packs ; manifolds

Key Features

• Stroke displacement: 7 cc
• Fits manifold: ac central manifold only
• Function: manual emergency operation of circuit
• Interface: screw in cartridge
• Use: operate actuator without electric power

Key Features

• Voltage: 12 vdc
• Power: 3 w rating
• Hole: 9 mm through-bore
• Body length: 30 mm
• Ingress protection: IP65
• Duty: 100% ed
• Use: electro-pneumatic 8EP3/8EP4 valves
