Double Counter Balance / Overcentre Valve 1/2" IN LINE 100-350 bar
Key Features
80L 1/2" Working section float spool 5BY-13NZL detent kit
GP20 Power Take Off Gear Pumps
FLOW DIVIDER/COMBINER 50/50 In line 3/8" BSP In/Out - 6,5-12 LPM
Sales Director
I began my engineering career at Stockport College in around 2005, first completing a National Diploma in Electrical Engineering, followed by a Higher National Diploma in Mechanical Engineering. I then progressed to the University of Salford, where I earned a BEng (Hons) degree in Mechanical Engineering.
After graduating, I started my professional career with Approved Hydraulics. I initially gained a combination of hands-on workshop experience and telephone-based sales experience. In later years, I moved into a full-time sales role and led the new crane and excavator attachments department that the company had recently established.
Group 2 Gear Pump 14cc Clockwise Rot. 9 Spline Shaft With 50mm Spigo - 250 Bar Cont. Pressure - DIN 5482
3/8" 3 Port Pressure Compensating Flow Control with bypass to line
45L - 50L 12V On/Off Electro Pneumatic Kit 8EP4 With With Manifold Block (30034555)
20cc Line Mounted Hand Pump C/w Release Valve and Handle
Double Counterbalance Valve 3/8" In Line - 100-350Bar
Clockwise Group 2 Tandem Hydraulic Pumps - Front
Proximity Switch
Z50 3/8" Solenoid Control Valves 50LPM 12/24VDC
3 WAY PRIORITY VALVE - EXCESS TO LINE 3/4"
45L - 50L 24V On/Off Electro Pneumatic Kit 8EP4 With With Manifold Block (30034555)
CETOP 5 Pressure Reducing Module - A to T (ZPR-10-D-A-1-210-YM)
CETOP 5 Pressure Reducing Module - P to T (ZPR-10-D-P-1-210-YM)
1/2" 3 Port Pressure Compensating Flow Control with bypass to line
100L Control Valve Double Acting Working Section 3/4"
150L Control Valve Mid Inlet Section With Direct Relief Valve (EI2 )
Hydraulic Motors (MP Series)
Group 2 Gear Motor 14cc/Rev , Euro Flange, 1:8 tpr Shaft, Reversible
Hydraulic Leg Lock off Valve - Isolator - Diverter valve 3/8"
CETOP 3 Pilot Operated Relief Valve Module - (Z-2-PB-6-VC-1-315)
1 1/2" Male/Female Low Pressure Ball Valve
Discover quality hydra part from Approved Hydraulics, trusted by professionals across construction, transport, forestry, agriculture and industrial sectors. Built for demanding working environments, our range offers dependable performance, durable construction and trusted reliability. Browse related products including lever operated monoblock valves, cetop 3 spares, scanreco spares accessories, scanreco to find the right solution for your hydraulic system. With fast UK delivery and expert technical support, Approved Hydraulics supplies hydraulic equipment you can rely on.
Calculating force, speed, pressure, power, and efficiency in hydraulic applications.
How do you calculate actuator speed?
Actuator speed is determined by flow rate and cross-sectional area: Speed = Flow rate ÷ Area Flow rate is the volume of fluid delivered (in L/min or GPM). Area is the cross-sectional area of the actuator piston: π × (diameter ÷ 2)².
How do you calculate cylinder force?
Cylinder force can be calculated using: Force = Pressure × Area Pressure is the system pressure (in psi or bar). Area is the cross-sectional area of the cylinder bore (in square inches or square centimeters). Area = π × (bore diameter ÷ 2)².
How do you calculate pressure drop across a valve?
Pressure drop can be calculated using the valve flow coefficient (Cv): Pressure Drop (ΔP) = (Flow Rate)² ÷ (Cv² × Fluid Density) Flow Rate is the fluid flow (in GPM or L/min). Cv is the valve flow coefficient. Fluid Density is the density of the hydraulic fluid.
How do you size an accumulator?
Accumulator sizing considers required flow, pressure, and pre-charge: Accumulator Volume = Flow Rate × Time ÷ Pressure This determines how much fluid must be stored to maintain system pressure.
How to convert psi to bar?
Use the conversion factor: 1 bar = 14.5 psi. To convert psi to bar, divide psi by 14.5. Example: 200 psi ÷ 14.5 = 13.79 bar.
What is pre-charge pressure in an accumulator?
Pre-charge pressure is the initial gas pressure in the accumulator before fluid enters. It helps maintain system pressure as the accumulator discharges. Typically set to 70–80% of system operating pressure.
What is specific gravity of hydraulic fluid?
Specific gravity is the ratio of hydraulic fluid density to water. A value of 1 means equal density. Less than 1 means the fluid floats; greater than 1 means it sinks.
What is torque in a hydraulic motor?
Torque is the rotational force produced based on system pressure and motor displacement: Torque = Pressure × Displacement ÷ 2π Pressure is the operating system pressure. Displacement is the volume displaced per revolution (in cubic inches or cubic centimeters).
What unit is hydraulic power measured in?
Hydraulic power is measured in horsepower (HP) or kilowatts (kW). Hydraulic horsepower can be calculated using: HP = (Pressure (psi) × Flow rate (GPM)) ÷ 1714.
What’s the relationship between pump speed and flow?
Flow rate is directly proportional to pump speed. If pump speed doubles, flow rate doubles (assuming constant displacement). This is important when adjusting flow or selecting a pump for varying speeds.
