3/8 BSPP Male Connection Poppet Check Valve - Cracking Pressure 0.5 Bar

The 3/8" UMC check valve is a compact, steel-bodied valve that permits one-way flow and blocks reverse flow. With a maximum capacity of 30 l/min and rated up to 60 bar, it is suitable for small-to-medium hydraulic circuits. Standard cracking pressure is 0.5 bar, with higher optional settings available.

Key Specifications for 3/8" UMC

• Port size: 3/8 BSPP

• Flow capacity: Up to 30 l/min (≈7.9 US gpm)

• Max working pressure: 60 bar (≈870 psi)

• Cracking pressure: Standard 0.5 bar (≈7.3 psi); optional 3 or 6 bar

• Weight & construction: Steel body; approx. 0.09 kg (≈0.20 lb)

DATA SHEET
