2 Port Manifold For SAE8/2 Cartridge 3/8” BSPP Ports - 350 Bar
Key Features
2 Port Manifold for SA10/2 Cartridge 1/2” BSPP Ports - 350 Bar
2 Port Manifold for SA10/2 Cartridge 3/8” BSPP Ports - 350 Bar
Tamper proof cap M10 - RED color
Sales Director
I began my engineering career at Stockport College in around 2005, first completing a National Diploma in Electrical Engineering, followed by a Higher National Diploma in Mechanical Engineering. I then progressed to the University of Salford, where I earned a BEng (Hons) degree in Mechanical Engineering.
After graduating, I started my professional career with Approved Hydraulics. I initially gained a combination of hands-on workshop experience and telephone-based sales experience. In later years, I moved into a full-time sales role and led the new crane and excavator attachments department that the company had recently established.
Tamper proof cap M8 - RED Color
Tamper Proof Cap M20-M22 - RED Color
Coil for Solenoid Valve 22W 24vDC
Coil for Solenoid Valve 22W 12vDC
1" BSPP Bi-directional Flow Control Valve
3/4" BSPP Bi-directional Flow Control Valve
BSPP One Way Flow Control Valve - Barrel Type
DIN 3/8" BSPP Double Acting Pilot Check Valve With Adjustable Banjo 12mm
3/4 BSPP Relief Valve - 80 l/min - 50/350 bar - Steel Body
3/8" BSPP Double Acting Pilot Check Valve
BSPP Adjustable Compensated Flow Control Valve
SAE8/2 Solenoid Valve Cartridge - Pilot Operated - 40 L/Min - 350bar
SAE10/2 Solenoid Valve Cartridge - Pilot Operated - 70 L/Min - 350bar - Checked in 1 Direction ONLY
SAE10/2 Solenoid Valve Cartridge - Pilot Operated - 70 L/Min - 350bar - Checked in BOTH Directions
BSPP Relief Valve upto 30 L/min - Steel Body
BSPP Relief Valve upto 50 L/min - Steel Body
3/8 BSPP CETOP 3 Single Manifold - 50 L/Min - 70/350 Bar - Aluminium Body
1/2 BSPP CETOP 5 Single Manifold - 80 L/Min - 20/210 Bar - Aluminium Body
BSPP One Way Flow Control Valves
Solenoid Operated Check Valves - Pilot Operated - 40 L/Min - 350bar
Discover quality fluid app hydraulic valves from Approved Hydraulics, trusted by professionals across construction, transport, forestry, agriculture and industrial sectors. Our range includes reliable components and equipment designed for dependable performance, long service life and straightforward installation. Whether you are replacing existing parts or specifying components for a new build, our experienced team can help you find the right product. With fast UK delivery and expert technical support, Approved Hydraulics supplies hydraulic equipment you can rely on.
Calculating force, speed, pressure, power, and efficiency in hydraulic applications.
How do you calculate actuator speed?
Actuator speed is determined by flow rate and cross-sectional area: Speed = Flow rate ÷ Area Flow rate is the volume of fluid delivered (in L/min or GPM). Area is the cross-sectional area of the actuator piston: π × (diameter ÷ 2)².
How do you calculate cylinder force?
Cylinder force can be calculated using: Force = Pressure × Area Pressure is the system pressure (in psi or bar). Area is the cross-sectional area of the cylinder bore (in square inches or square centimeters). Area = π × (bore diameter ÷ 2)².
How do you calculate pressure drop across a valve?
Pressure drop can be calculated using the valve flow coefficient (Cv): Pressure Drop (ΔP) = (Flow Rate)² ÷ (Cv² × Fluid Density) Flow Rate is the fluid flow (in GPM or L/min). Cv is the valve flow coefficient. Fluid Density is the density of the hydraulic fluid.
How do you size an accumulator?
Accumulator sizing considers required flow, pressure, and pre-charge: Accumulator Volume = Flow Rate × Time ÷ Pressure This determines how much fluid must be stored to maintain system pressure.
How to convert psi to bar?
Use the conversion factor: 1 bar = 14.5 psi. To convert psi to bar, divide psi by 14.5. Example: 200 psi ÷ 14.5 = 13.79 bar.
What is pre-charge pressure in an accumulator?
Pre-charge pressure is the initial gas pressure in the accumulator before fluid enters. It helps maintain system pressure as the accumulator discharges. Typically set to 70–80% of system operating pressure.
What is specific gravity of hydraulic fluid?
Specific gravity is the ratio of hydraulic fluid density to water. A value of 1 means equal density. Less than 1 means the fluid floats; greater than 1 means it sinks.
What is torque in a hydraulic motor?
Torque is the rotational force produced based on system pressure and motor displacement: Torque = Pressure × Displacement ÷ 2π Pressure is the operating system pressure. Displacement is the volume displaced per revolution (in cubic inches or cubic centimeters).
What unit is hydraulic power measured in?
Hydraulic power is measured in horsepower (HP) or kilowatts (kW). Hydraulic horsepower can be calculated using: HP = (Pressure (psi) × Flow rate (GPM)) ÷ 1714.
What’s the relationship between pump speed and flow?
Flow rate is directly proportional to pump speed. If pump speed doubles, flow rate doubles (assuming constant displacement). This is important when adjusting flow or selecting a pump for varying speeds.
